Bobcat S76

S76

The S76 R-Series skid-steer loader is designed to help you accomplish more with one machine. This 74-hp, vertical lift path skid-steer loader delivers powerful breakout forces, fast cycle times and increased lifting capabilities – including increased lift capacity and height. It is highly maneuverable, offering effective turning and skidding that is ideal for doing challenging work in tight areas. All this, plus you’ll experience a new level of operator comfort thanks to a roomy cab, ergonomic controls, optional automatic heat and air conditioning and more.

Pricing

• Daily Cost: Request a Quote
• Weekly Cost: Request a Quote
• Monthly Cost: Request a Quote

Features

• Adjustable Seat
• Backup Alarm
• BICS System (Interlock)
• Operating Lights
• Rear Window
• Lift-Arm Support
• Suspension Seat
• Auxiliary Hydraulics
• Bob-Tach Attachment System
• Horn

Frequently Rented With

• Breaker
• Auger
• Sweeper
• Pallet Forks
• Combination Bucket
• Industrial Grapple

S76

Dimensions

• LENGTH

  113.9 in

• LENGTH WITH BUCKET

  147.1 in

• HEIGHT

  81.8 in

• WIDTH

  72 in

• WIDTH WITH BUCKET

  74 in

• WEIGHT

  8,615 lb

• WHEELBASE

  48.3 in

• TURNING RADIUS

  87.9 in

• REACH AT MAX HEIGHT

  37.4 in

Engine

• ENGINE

  Tier 4

• HORSEPOWER

  74 hp

• FUEL TYPE

  Diesel

• FUEL TANK CAPACITY

  31.7 gal

• COOLING

  Liquid

Hydraulics

• AUXILIARY STD FLOW

  23.3 gal/min

• AUXILIARY HIGH FLOW

  30.3 gal/min

• SYSTEM RELIEF AT QUICK COUPLERS

  3,450 psi

Operational

• RATED OPERATING CAPACITY

  2,900 lb

• TIPPING LOAD

  5,800 lb

• TRAVEL SPEED

  10.9 km/h
