< Buckets

Trenching Buckets – Class 4

Want to rent before you buy? SEE RENTALS

Request a Quote

Trenching Buckets – Class 4

This bucket is the best attachment for your general digging tasks. The standard tooth trenching bucket has been redesigned to give you maximum strength and durability for severe digging and prying. Plus, the X-change mounting system lets you swap buckets out with ease. Compatible with the Bobcat E32, E35 & E42.

Used For

  • Digging trenches
  • Water, power and telecommunications jobs
  • Sewer and drainage projects

Options

  • X-Change mounting system
  • Shorter tip radius and deeper bowl
  • Replaceable cutting edge
  • Weld-on shanks
  • Cast side cutters
  • X-Change reinforcement plate (18” and up)

Trenching Buckets – Class 4

Trenching Bucket - Class 4 - 12"

  • WEIGHT
    137 lb
  • LENGTH
    20.4 in
  • WIDTH
    12 in
  • HEIGHT
    16.3 in
  • ISO HEAPED CAPACITY
    1.2 ft³
  • ISO STRUCK CAPACITY
    1 ft³

Trenching Bucket - Class 4 - 18"

  • WEIGHT
    257 lb
  • LENGTH
    33.2 in
  • WIDTH
    18 in
  • HEIGHT
    25.2 in
  • ISO HEAPED CAPACITY
    4.2 ft³
  • ISO STRUCK CAPACITY
    2.6 ft³

Trenching Bucket - Class 4 - 24"

  • WEIGHT
    301 lb
  • LENGTH
    33.2 in
  • WIDTH
    24.2 in
  • HEIGHT
    25.2 in
  • ISO HEAPED CAPACITY
    5.9 ft³
  • ISO STRUCK CAPACITY
    3.7 ft³

Trenching Bucket - Class 4 - 30"

  • WEIGHT
    353 lb
  • LENGTH
    33.2 in
  • WIDTH
    30.2 in
  • HEIGHT
    25.2 in
  • ISO HEAPED CAPACITY
    7.6 ft³
  • ISO STRUCK CAPACITY
    4.8 ft³

Trenching Bucket - Class 4 - 36"

  • WEIGHT
    439 lb
  • LENGTH
    33.2 in
  • WIDTH
    36.2 in
  • HEIGHT
    25.2 in
  • ISO HEAPED CAPACITY
    9.3 ft³
  • ISO STRUCK CAPACITY
    5.8 ft³
