Tree Spade

Tree Spade

Transplanting trees has never been easier with the Bobcat tree spade attachment. Built for maximum durability, the reinforced attachment frame handles the bumps and bruises of a tough work environment and its compact size easily squeezes between closely-planted trees. Control its operation with the fingertip controls integrated into the loader control handles to dig, transplant, and package trees without leaving the comfort of the operator’s seat. The rugged, dependable tree spade attachment turns any loader into a transplanting unit, while also speeding up production and cutting labor costs.

Used For

• Digging and transplanting trees
• Nurseries, landscapers, construction & farming

Features

• Adjustable Legs: Allows for digging 5 different root-ball sizes with 1 tree spade.
• Blade Versatility: Modified and cone blade configurations are available.
• Bobcat® Orange Color: Delivers better attachment visibility when digging.
• Compact Design: Allows for attachment operation in confined areas.
• Open Frame Design: Provides excellent visibility to the base of the tree.
• Outside Frame Design: Provides a wider space for the tree.
• Inside Frame Design: Helps maintain the integrity of the root-ball and allows for a more compact design.
• Overlapping Blades: Ensure clean root cutting and support of the root-ball.

Options

• 7-pin Attachment Control Device: Control tree spade operation with fingertip controls located directly on the steering levers of the carrier.
• Convertible Valve: Control tree spade operation with fingertip controls on the steering levers or by using a pendant control box.
• Valve Options: Choose from a convertible valve or dedicated ACD valve.

Tree Spade

Convertible Cone - 32"

• WEIGHT

  1,590 lb

• LENGTH

  83.3 in

• WIDTH

  91.8 in

• HEIGHT

  64.2 in

• TREE DIAMETER

  2 - 3.25 in

Convertible Modified - 32"

• WEIGHT

  1,525 lb

• LENGTH

  74.2 in

• WIDTH

  76 in

• HEIGHT

  58.7 in

• TREE DIAMETER

  2 - 3.25 in

Convertible Cone - 36"

• WEIGHT

  1,640 lb

• LENGTH

  87.5 in

• WIDTH

  95.6 in

• HEIGHT

  64.2 in

• TREE DIAMETER

  2 - 3.75 in

Convertible Modified - 36"

• WEIGHT

  1,580 lb

• LENGTH

  78.4 in

• WIDTH

  79.8 in

• HEIGHT

  58.7 in

• TREE DIAMETER

  2 - 3.75 in

Convertible Cone - 44"

• WEIGHT

  2,150 lb

• LENGTH

  85.1 in

• WIDTH

  85.1 in

• HEIGHT

  64.2 in

• TREE DIAMETER

  3 - 4.5 in

Convertible Modified - 44"

• WEIGHT

  2,145 lb

• LENGTH

  78.5 in

• WIDTH

  77.7 in

• HEIGHT

  66.6 in

• TREE DIAMETER

  3 - 4.5 in
