Severe Duty Buckets

Severe Duty Buckets

Our severe duty buckets are built to take on your toughest jobs and stand up to any challenge. They feature taller and thicker side cutting edges, a stronger mounting frame and a double-walled top cross member to control heavy duty material handling, levelling and grading. Its pre-drilled holes allow for the easy installation of a number of custom accessories, all by using simple tools. Put it to the test and it’ll pass every time.

Used For

• Carrying and loading
• Material handling
• Heavy-duty grading
• Heavy-duty leveling

Features

• Great cutting edge visibility: A better view means better precision.
• Reinforced bucket back: Better reinforcement in the right areas gives the bucket high breakout force.
• 1 in x 8 in cutting edge: Withstands higher breakout forces.
• Cast mounting frame: Improves the service life of this attachment.
• Round back design: Enhances the bucket cleanout and loading ability.
• Waffle type skid plate: The reinforced cutting edge adds strength to the bottom of the bucket.
• Channel design: Extra strength and durability is given by the top and bottom bucket sections being a formed channel design.

Options

• Bucket Bite® Tooth Bar: Easily convert to a toothed bucket from a smooth-lip bucket.
• Bolt-on teeth with replaceable points: Cut through tough digging conditions with a variety of styles.
• Bolt-on cutting edge: Gives your bucket a longer life.
• Bolt-on corner cutting edge: beveled cutting edges that protect the corners of your bucket.
• Bucket spill guard: Reduces the ability of material boiling or falling over the back of the bucket.

Severe Duty Buckets

Severe Duty Bucket - 82"

• WEIGHT

  844 lb

• LENGTH

  38.2 in

• WIDTH

  82 in

• HEIGHT

  24.3 in

• NUMBER OF TEETH

  8 bolt-on

• ISO HEAPED CAPACITY

  22.8 ft³

• ISO STRUCK CAPACITY

  16.7 ft³

• PREDRILLED FOR

  Bolt-on edges or teeth

Severe Duty Bucket - 88"

• WEIGHT

  888 lb

• LENGTH

  38.2 in

• WIDTH

  88 in

• HEIGHT

  24.3 in

• NUMBER OF TEETH

  9 bolt-on

• ISO HEAPED CAPACITY

  24.6 ft³

• ISO STRUCK CAPACITY

  18 ft³

• PREDRILLED FOR

  Bolt-on edges or teeth
