< Bobcat Attachments

Angle Blade – CT

Want to rent before you buy? SEE RENTALS

Request a Quote

3-Point Angle Blade (Compact Tractor)

The compact tractor angle blade is an economical choice for backfilling, levelling, grading and removing snow on farms or acreages. It doesn’t require PTO, can be rotated a full 360° and angled to move materials from either side of your machine. It can be used in both forward and reverse, allowing you to push material in short runs or scrape it. It is a vital tractor implement for any grounds maintenance and landscaping work.



Used For

  • Pushing and scraping snow from roads or parking areas
  • Grading gravel roads and driveways
  • Levelling land or backfills

Features

  • Rotates/Reverses: Rotates a full 360° with five forward and five reverse settings.
  • Three Widths: Available in 60-in, 72-in and 84-in blade widths.
  • Category 1 3-Point Hitch: Attaches your rear-mounted angle blade implement.

3-Point Angle Blade (Compact Tractor)

3-Point Angle Blade - 60"

  • WEIGHT
    308 lb
  • LENGTH
    40 in
  • WIDTH
    60 in
  • MOLDBOARD WIDTH
    60 in
  • MOLDBOARD DIMENSION
    15 in
  • CUTTING EDGE
    6 in
  • HITCH
    Category 1
  • ADJUSTMENT TYPES
    Manual (360° rotation)
  • OFFEST MAX
    12 in left or right
  • FORWARD PIVOT
    5 positions (7° each)
  • REVERSE PIVOT
    5 positions (7° each)

3-Point Angle Blade - 72"

  • WEIGHT
    332 lb
  • LENGTH
    40 in
  • WIDTH
    72 in
  • MOLDBOARD WIDTH
    72 in
  • MOLDBOARD DIMENSION
    15 in
  • CUTTING EDGE
    6 in
  • HITCH
    Category 1
  • ADJUSTMENT TYPES
    Manual (360° rotation)
  • OFFEST MAX
    12 in left or right
  • FORWARD PIVOT
    5 Positions (7° each)
  • REVERSE PIVOT
    5 Positions (7° each)

3-Point Angle Blade - 84"

  • WEIGHT
    348 lb
  • LENGTH
    40 in
  • WIDTH
    84 in
  • MOLDBOARD WIDTH
    84 in
  • MOLDBOARD DIMENSION
    15 in
  • CUTTING EDGE
    6 in
  • HITCH
    Category 1
  • ADJUSTMENT TYPES
    Manual (360° Rotation)
  • OFFEST MAX
    12 in left or right
  • FORWARD PIVOT
    5 Positions (7° each)
  • REVERSE PIVOT
    5 Positions (7° each)
